Type 18/24 MGM ADB Spring Brake- 2.50 Inch Stroke

Don't settle for average braking performance when you can upgrade to the MGM ADB Spring Brake Type 18/24. This top-tier spring brake chamber is designed for durability and consistent performance under demanding loads. Featuring a 2.5-inch long stroke, air disc non-pressure chamber, and nitrile rubber air seal, it guarantees precision and stability in every stop. Its epoxy-coated head and 360 aluminum center case resist rust and wear, while the HD nylon reinforced diaphragms and external breather tube protect internal components from the elements. Built to replace K043329, GC1824D, and TRB1824DT051, this MGM ADB 18/24 brake keeps your rig road-ready and reliable.

* High Quality Spring Brake
* 18/24 Type
* 2.5 Inch Long Stroke
* 0.591" In Caged Lower Position Push Rod
  - Molded Nitrile Rubber Air Seal
* Air Disc Non-Pressure Chamber
* Return Spring
* Weather seal Plug
* External Breather Tube
* Epoxy Coated Head
* HD Nylon Reinforced Diaphragms
* 360 Aluminum Center Case
* (2) M16 - 1.5 Bolts, 4.750 Inch Center To Center
* (1) 1/2 Inch - 13 Bolt
* (2) 3/8 Inch NPTF Ports
* 8.810 Inch Body Height
* Sold Individually
* Warranty On Spring Brakes Against Defects In Workmanship & Material From Date Of Purchase

*** High Quality Aftermarket Replacement Part (Not OEM)***

* Cross Ref # TRB1824DT051, K043329
