Sleeve Type Cabin Air Spring- Load At 80 PSI - 688 Lbs, Load At 100 PSI - 860 Lbs

Improve ride comfort and cab stability with this high-quality Cabin Air Spring. This sleeve-type air spring supports 688 lbs at 80 PSI and 860 lbs at 100 PSI, with a top plate diameter of 2.99 inches and bottom plate featuring stud holes and threaded connections. With a design height of 5.2 inches and adjustable height range of 2.2-8.5 inches, it delivers reliable cab suspension. Sold individually, it ensures smooth, durable ride performance.

* High Quality Air Spring Cabin
* Sleeve Type
* Load At 80 PSI - 688 Lbs
* Load At 100 PSI - 860 Lbs
* Top Plate:
  - 2.99 Inch Diameter
* Bottom Plate:
  - (1) Hole/Stud
  - 3/4 Inch - 16 UNF
  - 1/8 Inch - 27 NPTF
  - 2.91 Inch Diameter
* No Bumper
* Dimensions:
  - 5.2 Inch Design Height
  - 2.2 Inch Minimum Height
  - 8.5 Inch Maximum Height
  - 4.4 Inch Maximum Diameter
* Sold Individually
* Warranty On Air Spring Cabins Against Defects In Workmanship & Material From Date Of Purchase

*** High Quality Aftermarket Replacement Part (Not OEM)***

* Cross Ref # 75314, SC29-O132, 7155, 7164, W023587155, W02-358-7155, W027037163, W02-703-7163, W027037164, W02-703-7164, W027037165, W02-703-7165, 1S4235, 1S4-235, R816002, R81-6002, W027037153, W02-703-7153, 2019036, 20-19036
